The advantage of an airborne sensor

An airborne receiving module supports monitoring and analysis of communications that terrain can obscure from ground sensors. Detection, classification and location capability depend on the chosen equipment and conditions; the receiver itself is not a jammer.

Radio activity in the area of interest
Survey

Payload matched to the task

Reconnaissance configuration
Signal reception and analysis
Jamming configuration
Active measures defined by the mission

Payload matched to the task

Reconnaissance configuration
Signal reception and analysis
Jamming configuration
Active measures defined by the mission

Survey and active protection in one architecture

Radio surveillance and active protection are separate configurations. A receiving module cannot automatically provide jamming. Any active capability requires dedicated equipment and separate integration and operating approval; the catalogue below describes receiving systems only.

With a suitable jamming payload
Jamming
01 03Equipment

Electronic warfare subcategories

Signal retransmissionExtend tactical networks beyond line of sight.Explore subcategory →Radar technologiesSAR surface imaging and a separate GPR option for subsurface surveys.Explore subcategory →

Configure your payload

Discuss requirements

What do you need to achieve?

Select the required function instead. We will work with you to specify the equipment.

Continue to enquiry and selection (0)

References and projects

URC Systems + JISR Institute · SYMON Craft

In October 2023, URC Systems tested the underslung SYMON Craft receiving module on a LIAZ helicopter with LIAZ and JISR Institute.

URC Systems · 26 Oct 2023
Choose a specific device for integration assessment3 catalogue models · specifications and sources

Models shown: 3 / 3

URC Systems

SYMON Craft

Airborne receiving module

Flight testing · 2023

A receiving system for radio surveillance and communications-signal analysis.

Category
COMMS-ESM
Manufacturer-listed bands
VHF / UHF / SHF
Data acquisition
Spectrum monitoring and recording
Assessment
Technical analysis and classification
Intended platforms
Manned aircraft and UAVs

The manufacturer must confirm weight, power draw and measurement accuracy for the selected installation.

CRFS

RFeye Node 100-18 LW

Passive RF receiver

Catalogue alternative · integration unconfirmed

A wideband receiving module for recording and subsequent analysis of the radio spectrum.

Receive frequency range
9 kHz–18 GHz
Instantaneous bandwidth
100 MHz
Sustained I/Q streaming bandwidth
12.5 MHz
Network interface
1 GigE
RF inputs
3

100 MHz bandwidth does not mean continuous recording of that entire bandwidth. Confirm weight and antenna assembly: the manufacturer's introduction lists 1.98 kg, while its table lists 1.95 kg.

Rohde & Schwarz

EM200

Compact monitoring receiver

Catalogue alternative · integration unconfirmed

A receiver for spectrum observation and I/Q output to downstream processing.

Frequency range
8 kHz–8 GHz
Real-time bandwidth
40 MHz
I/Q streaming: standard / option
1 MHz / 40 MHz
Weight
Approximately 3.5 kg
Supply voltage
10–32 V DC
Typical power, depending on options
18–20 W

Figures are from the EM200 v1.00 fact sheet. Without suitable antennas, options and analysis, the receiver is not a complete direction-finding or ELINT system. Airborne integration is not confirmed.
